Περιγραφή
| Model Number | A15 |
| Main Board | |
| Processor |
Intel® Core™ J1900 Processor TDP 10W |
| Chipset | CPU Integrated Graphic/ Intel Nm70 TDP 4.1W/ I3-3227U+HM76 |
| System Memory | 4GB DDR3 1333MHz*SODIMM Socket , up to 4GB |
| Display Chip: | Intel GMA 3650 D*9
Intel GMA HD Graphic D*11 Intel HD 4000 |
| OS Support | Windows98/2000/2003/ Windows XP Pro, Vista, Windows 7/8, Android OS/DOS |
| Display | |
| Screen Size | 15.6 Inch |
| Resolution | 1024 x 768 Pixel / 800x 600 Pixel |
| Display Type | TFT LCD |
| Display Color | 16.7M |
| Contrast Radio | 450:1 |
| Video In | VGA R/G/B |
| Response Time | 12ms |
| Touch Sensor | Resistive |
| Touch Controller | USB Interface or Serial Port |
| Power-driven Tilt Adjustment | N/A |
| Storage | |
| HDD | MSATA32/64/128GB SSD or 2.5” 500GB HDD |
| Compact Flash | 1x Slot Type II, Non-removable |
| I/O Ports | |
| Serial | 2x RS232 (1 external, 1 internal) |
| Parallel | 1 x Parallel Port |
| USB | 6x USB2.0 High-speed Interface, Support OTG Function
(4x External, 2x Internal) |
| LAN | 1 x RJ45 10/100M Base-T |
| VGA | 1 x |
| Audio Jack | 1 x Line-out MIC in& SPK out |
| DC Out | 1 x 12V DC Jack for Customer Display |
| AC In | 12V/6A |
| Others | |
| Power Input | External Adaptor: 100~240 VAC |
| Color | Black/ Customized |
| Diskless Boot | Support |
| Certifications | CCC/FCC/CE/ RoHS |
| Environment | |
| Operating Condition | 5°C~+40°C (41°F~ +140°F )
non-condensing max, wet bulb 26℃ (78.8 °F ) |
| Storage Condition | -20°C~ 60°C (-4°F~ +140°F )
non-condensing max, wet bulb 28.9℃ (84.0 °F ) |
| Storage Humidity |
20% – 80% RH, non-condensing |
